Project Information
A complete 10kW on-grid solar system installed on a private residence in Lahore. The family was facing electricity bills of over PKR 60,000 in peak summer months. We designed a rooftop system sized to cover almost their entire daytime load and feed surplus units back to the grid through net metering.
Project Info:
- Client:Residential Homeowner
- Category:Residential Solar
- Location:Lahore, Punjab
- System Size:10 kW On-Grid
- Completed:2025
Scope of Project
Our team carried out a full site survey, shadow analysis and load assessment before finalising the design. We installed Tier-1 mono PERC panels on a custom galvanised-iron structure angled for Lahore's latitude, wired the array to a high-efficiency on-grid inverter, and completed the LESCO net-metering application and documentation on the customer's behalf.
- Full rooftop survey & shadow analysis
- Tier-1 mono PERC solar panels
- LESCO net-metering approval handled end-to-end
- Online monitoring app set up for the customer
- 18 × 550W Tier-1 Mono PERC panels
- 10kW on-grid string inverter
- Galvanised mounting structure
- AC/DC protection & net-metering bi-directional meter
The Result
The system now generates around 1,300–1,500 units per month. The customer's grid bill dropped by close to 90%, and exported surplus units further offset their winter consumption. Expected payback on the investment is roughly 3 years.
